Cage size range

100×100/100×150/150×150mm(customized)

Cage length

3m

Spiral wire diameter

3.0 ~ 4.0mm

The longitudinal bar diameter

4.0mm

Spiral pitch

60 ~ 70mm

Welding line speed

Max.3000mm/min

Drive motor

8.4Kw

Welding power

200KVA

Main engine speed

0-64R/min

Welding method

Resistance welding

Control method

Automatic

Tensile or shear force at the welding point

≥ 200KG

Cooling methods for welding transformers

air cooling, self cooling
