Single wire Diameter

Φ5-12mm

 coiled round smooth steel&deformed steel

Double wires Diameter

Φ5-10mm

 coiled round smooth steel&deformed steel

Max Stirrup side length

1200mm

Min Stirrup Size Length

60mm

Bending angle （ bidirectional bending ）

0-180°

Length tolerance

±1mm

Bending angle tolerance

±1°

Rated total power

31.5 KW

Traction motor power

servo motor 18KW

Bending motor power

servo motor 5.5KW

Cutting motor power

4 KW

Air compressor power

4 KW

Traction speed

110m/min(MAX)

Bending Speed

1100°/Second(MAX)

Voltage

380V 3phases 50HZ

Overall dimension

3500*1050*2200mm
